GN2376
Hinge Plates with Threaded Studs, Stainless Steel, for GN7237 & GN235
Please select desired options to reveal part number, price and availability
Options
L - Fixing angle piece left
R - Fixing angle piece right
Product Description
GN7237 Multiple Joint Hinge, Stainless Steel, Inside, Opening Angle 180°
Stainless steel multiple joint hinges GN 7237 are installed on the inside of flaps, hatches and doors to save space and ensure protection against vandalism. The hinges have a maximum opening angle of 180°, which provides optimal accessibility and avoids the blocking of escape routes by open doors, for example.
Use of this hinge type leaves housing exteriors free of attachments that do not match the design or that should be avoided entirely in the interests of fast and easy cleaning.
Stainless steel multiple joint hinges are generally used in pairs, meaning that one type L and one type R are used per opening. For higher loads, e.g. from large hatches, these can be supplemented with additional hinges of either type.
Specification
Stainless Steel NI AISI 304, matte, ground MT
Friction bearing - Bronze, self lubricated
On Request
Other opening angles, other fixing angle pieces, other materials, other finishes, other max. wall thicknesses, other lifting motion.
