GN438.5 Spacer & Foot Discs, Stainless Steel, Rubber Underlay

Choose your Part

Please select desired options to reveal part number, price and availability

Options

Type A - Mounting with fixing hole

Type B - Mounting with adhesive pad

Product Description

GN438.5 Spacer Discs & Foot Discs, Stainless Steel, with Vulcanised Rubber Underlay

GN 438.5 Stainless Steel-Spacer discs and foot discs provide a damping and muffling function and protect surfaces from damage.

By stacking several spacer discs on each other, the spring rate of the package can be increased, which opens up new possibilities for use.

Foot disks are used for installing small machines, systems or devices and, for type A, are attached with screws. Bear in mind the maximum height of the screw head. Alternatively, type B can be stuck to all suitable, clean surfaces by means of the adhesive pad.

Specification

• Stainless Steel AISI 304
• Rubber underlay - Acrylonitrile butadiene rubber (NBR), vulcanized, black, temperature resistant up to 120 °C, Hardness Shore A 70
• Adhesive pad (Type B) - Scotch mount TM 5952, double-sided. Acrylate rubber core

On Request

Other Shore hardnesses
