Please select desired options to reveal part number, price and availability
Options
Shape B - Basic model with wire hole
Shape T - Circular punch point guiding shape
Mouldable area 0 - Short version
Mouldable area 10 - Long version
Product Description
42S Stripper Head for Nitrogen Punching Unit
These 42S Stripper heads are used for Nitrogen Punching Units 3LP or Nitrogen Stipper Units 3LB.
The short stripper head is recommended for flat piercing. Any moulded contour of the stripper head will cause a lost of working stroke.
The long stripper head is recommended for piercing where it is required a moulded contour of the stripper. The mouldable area of the stripper is 10 mm long and shall be machined by the user.
It can be supplied with or without (basic model) punch point guiding shape built-in.
The maximum working stroke of the stripper head is always 8 mm. The maximum working stroke of the stripper head shall be always calculated from the first point of contact of the stripper with the working area of the sheet.
All other Shapes on request please contact our sales team sales@berger-tools.co.uk
CAD Viewer
Technical Data
