DIN3670 Disc Handwheel, Aluminium, Recessed Grips

CloseNextPrevious
CloseNextPrevious
CloseNextPrevious
CAD Viewer Technical Data

Series Selector

Options

Bore code B - without keyway

Bore code K - with keyway

CAD Viewer Technical Data

Product Description

DIN3670 Disc Handwheel, Aluminium, Recessed Grips.

These handwheels have an attractive dished design and have recesses in the back for a easy, comfortable grip. They are used amongst other applications for the accurate adjustment of machinery. Usually these handwheels are supplied without a handle, although the mounting of a handle is possible.

Specification

Aluminium AL

Hub - Machined.

Rim - Turned and polished, concentric and square to bore < 0.4

Body - Unmachined, shot-blasted.

SELECT HasTableOnOff FROM Series WHERE SeriesID=68
