Please select desired options to reveal part number, price and availability
Options
Type B - without rest position
Type C - with rest position
Product Description
GN822 Mini Indexing Plunger, Covered Indexing Mechanism
Mini indexing plungers GN 822 are known for their small dimensions. They have been designed for installation in thin walled sheet metal constructions.
They are inserted into position by holding them by the serrated knob. The spanner flats on the lock nut are revealed when retracting the pin, so that the mini indexing plunger can be easily tightened by means of a fork spanner.
Specification
Steel ST, zinc plated, blue passivated, Stainless Steel NI AISI 303
Plunger - Stainless Steel NI AISI 303
Spring - Stainless Steel NI AISI 303
Knob Plastic - Technopolymer (Polyamide PA), black, matt finish, not removable.
CAD Viewer
Technical Data
