GN187.4 Serrated Locking Plate, Sintered Steel





Type A - with tapped hole d3 in the center, with two countersunk holes for cap screws

Type B - with drilling d4 in the center, with two countersunk holes for cap screws

Type C - with tapped hole d3 in the center, with two tapped mounting holes d6

Type D - with drilling d4 in the center, with two tapped mounting holes d6

Type E - without drillings, blank, not hardened

Select Values to Buy:

Tech Spec:



GN187.4 Serrated Locking Plate, Sintered Steel

With the aid of these serrated locking plates, standard components can be interlocked and set firmly at a defined angle.

The angular position of the fixing bores in relation to the serrations is not defined in the standard design. The exact positioning is available as special design.

The range of designs makes these plates adaptable for almost any application in this particular field.

To complement these toothed clamping elements, accessories such as guide pots GN187.1 and thrust springs GN187.2 are useful additional standard parts. Serrated locking plates are also available in stainless steel - GN187.4

Specification

Sintered Steel (Distaloy AB) ST, hardened, black oxidised with vapor. Type E: not hardened, blank.

RoHS compliant



Select / Deselect Visible Columns
PartCoded1Number
of teeth
TypeMateriald2d3d4d5d6d7h1h2m1m2wMass

GN187.4-22-48-A-ST2248AST15.5M44.23.2M336.51312120.60.013
GN187.4-22-48-B-ST2248BST15.5M44.23.2M336.51312120.60.013
GN187.4-22-48-C-ST2248CST15.5M44.23.2M336.51312120.60.013
GN187.4-22-48-D-ST2248DST15.5M44.23.2M336.51312120.60.013
GN187.4-22-48-E-ST2248EST15.5M44.23.2M336.51312120.60.015
GN187.4-22-60-A-ST2260AST15.5M44.23.2M336.51312120.60.013
GN187.4-22-60-B-ST2260BST15.5M44.23.2M336.51312120.60.013
GN187.4-22-60-C-ST2260CST15.5M44.23.2M336.51312120.60.014
GN187.4-22-60-D-ST2260DST15.5M44.23.2M336.51312120.60.014
GN187.4-22-60-E-ST2260EST15.5M44.23.2M336.51312120.60.02
GN187.4-27-48-A-ST2748AST19.5M55.24.3M447.51515150.70.022
GN187.4-27-48-B-ST2748BST19.5M55.24.3M447.51515150.70.022
GN187.4-27-48-C-ST2748CST19.5M55.24.3M447.51515150.70.022
GN187.4-27-48-D-ST2748DST19.5M55.24.3M447.51515150.70.024
GN187.4-27-48-E-ST2748EST19.5M55.24.3M447.51515150.70.027
GN187.4-27-60-A-ST2760AST19.5M55.24.3M447.51515150.70.022
GN187.4-27-60-B-ST2760BST19.5M55.24.3M447.51515150.70.021
GN187.4-27-60-C-ST2760CST19.5M55.24.3M447.51515150.70.024
GN187.4-27-60-D-ST2760DST19.5M55.24.3M447.51515150.70.024
GN187.4-27-60-E-ST2760EST19.5M55.24.3M447.51515150.70.02
GN187.4-32-48-A-ST3248AST23.5M66.25.3M5591818180.90.036
GN187.4-32-48-B-ST3248BST23.5M66.25.3M5591818180.90.036
GN187.4-32-48-C-ST3248CST23.5M66.25.3M5591818180.90.036
GN187.4-32-48-D-ST3248DST23.5M66.25.3M5591818180.90.036
GN187.4-32-48-E-ST3248EST23.5M66.25.3M5591818180.90.046
GN187.4-32-60-A-ST3260AST23.5M66.25.3M5591818180.90.037
GN187.4-32-60-B-ST3260BST23.5M66.25.3M5591818180.90.036
GN187.4-32-60-C-ST3260CST23.5M66.25.3M5591818180.90.041
GN187.4-32-60-D-ST3260DST23.5M66.25.3M5591818180.90.04
GN187.4-32-60-E-ST3260EST23.5M66.25.3M5591818180.90.046
GN187.4-40-48-A-ST4048AST30M88.26.3M6611.52323231.30.073
GN187.4-40-48-B-ST4048BST30M88.26.3M6611.52323231.30.072
GN187.4-40-48-C-ST4048CST30M88.26.3M6611.52323231.30.081
GN187.4-40-48-D-ST4048DST30M88.26.3M6611.52323231.30.08
GN187.4-40-48-E-ST4048EST30M88.26.3M6611.52323231.30.089
GN187.4-40-60-A-ST4060AST30M88.26.3M6611.52323231.30.073
GN187.4-40-60-B-ST4060BST30M88.26.3M6611.52323231.30.073
GN187.4-40-60-C-ST4060CST30M88.26.3M6611.52323231.30.08
GN187.4-40-60-D-ST4060DST30M88.26.3M6611.52323231.30.079
GN187.4-40-60-E-ST4060EST30M88.26.3M6611.52323231.30.09
