Product Description
GN355 Levelling Element, Stainless Steel, with Levelling Screw
These levelling elements, GN 355, are used for levelling and adjusting machines and equipment. They are ideal for hygienic, cleanroom environments, such as in the food and medical industries.
They consist of a levelling screw, a cylinder screw with disk and a spherical washer. After making the adjustment using assembly tool GN355.1, the screw is tightened firmly causing the levelling screw and the spherical washer DIN6319 underneath to spread and is so secured against twisting in the taphole.
The values for w and x given in the table and for the static load capacity are to be seen as reference values which may differ depending on the prevailing situation. In general, they do not constitute a warranty of condition. The user must determine whether the product is suitable for the intended purpose.
Specification
Levelling element - Stainless Steel NI AISI 303
Cylinder head screw DIN912 - Stainless Steel NI, A2-70
Washer DIN 433 - Stainless Steel NI, AISI 304
Spherical washer - Stainless Steel NI, AISI 303
Accessory
Asembly tool GN355.1
CAD Viewer
Technical Data
