GN709.1 Clamping Pads Male spring plunger workpieces threaded Steel

Standard Machine Elements > Screws, Nuts, Washers Clamping & Supporting Elements > Positioning Elements / Clamping Pads
< Previous Product Next Product >

GN709.1 Clamping Pad, Male Thread, Steel





Type B - smooth contact face

Type R - serrated contact face

Select Values to Buy:

Tech Spec:



GN709.1 Clamping Pad, Male Thread, Steel

These clamping pads with ball pin, GN709.1, are used as mobile supports or as spring plungers for clamping workpieces. They can also be used as a back stop.

The ball is limited to an angular movement of 9 degrees.

Also available with serrated hard metal ball insert, on request.

Specification

Steel - Tempered, phosphate treated.

Ball - hardened, blank.

RoHS compliant

Also available in female variant, and in stainless steel.

Select / Deselect Visible Columns
PartCodeMateriald1d2d3d4l1l2l3A/FStatic
load
max.
in kN
TypeMass

GN709.1-13-M6-BST13M67.210131381110B0.012
GN709.1-13-M6-RST13M67.210131381110R0.012
GN709.1-13-M8-BST13M87.210131381110B0.012
GN709.1-13-M8-RST13M87.210131381110R0.013
GN709.1-20-M8-BST20M810.5161818101725B0.038
GN709.1-20-M8-RST20M810.5161818101725R0.038
GN709.1-20-M10-BST20M1010.5161818101725B0.04
GN709.1-20-M10-RST20M1010.5161818101725R0.02
GN709.1-20-M12-BST20M1210.5161818121725B0.05
GN709.1-20-M12-RST20M1210.5161818121725R0.04
GN709.1-30-M16-BST30M1620252727162790B0.15
GN709.1-30-M16-RST30M1620252727162790R0.15
GN709.1-50-M20-BST50M2034.54035352041165B0.52
GN709.1-50-M20-RST50M2034.54035352041165R0.52
