Standard Machine Elements > Toggle Clamps, Power & Hook Clamps > Toggle Clamps
< Previous Product Next Product >

GN851 Latch, Steel, Zinc Plated, Pulling Action Clamp





Type T2 - with pulling latch, with latch bracket.

Type T - without pulling latch, with latch bracket.

Select Values to Buy:

Tech Spec:



GN851 Latch, Steel, Zinc Plated, Pulling Action Clamp

These latch clamps provide safe locking of lids and covers. The stroke of the pulling latch can be adjusted within its range.

In the clamped position the operating lever with clamping arm is parallel to the plane of the operating lever.

Besides the standard dimensions of the pulling latch above, more versions are available under GN951.1

Specification

Parts in sheet metal - Case hardening steel C10, zinc plated, blue passivated.

Pulling latch - steel St 37, zinc plated, blue passivated.

All moving parts lubricated with special grease.

Handle with plastic sleeve - red, oil resistant.

RoHS compliant

Select / Deselect Visible Columns
PartCodeSizeTypeMaterialFH in N
Holding
Capacity
ab1b2b3b4b5d1d2h1h2l1l2m1m2m3m4m5rsw1w2Mass

GN851-160-T2160T2C101600122628212014M44.3261898111951651035225110.08
GN851-160-T160TC101600122628212014M44.3261898111951651035225110.072
GN851-320-T2320T2C103200164044322822M66.53025152193210.519714.357348100.25
GN851-320-T320TC103200164044322822M66.53025152193210.519714.357348100.225
GN851-700-T2700T2C107500246054383826M88.5423622021389.541.59.519743.558220.62
GN851-700-T700TC107500246054383826M88.5423622021389.541.59.519743.558220.527
