DIN808 Stainless Steel Universal Joint
Type EG - single, friction bearing.
Type DG - double, with friction bearing.
Bore Code d2:
B - without keyway.
K - with keyway.
V with square - available on request - please call for further details.
iso-fundamental tolerance series page 2.pdf
keyway and key details din 6885 page 1.pdf
cross holes gn 110.pdf
Catalogue Technical Specification
2D/3D Cad Files
DIN 808 Stainless Steel Universal Joint with Friction Bearing.
Since the moveable parts are not surface treated, i.e. not case hardened, the possibilities of application of these universal joints are much more limited compared to the ones made of standard steel. Therefore, the guide lines for the selection of universal joints with friction bearing according to the diagram may be applied at a limited extent only. Rotational speeds over 200 min may become critical.
For continuous use of the Stainless Steel-Universal joints, ample lubrication is very important. This achieved by fitting the joint with a grease filled gaiter GN808.1
Stainless Steel NI AISI 304
