Standard Machine Elements > Universal, Ball Joints & Fork Joints > Ball Joints

GN782 Ball Joint, Steel





Type KS - Ball With Male Thread

Type KI - Ball With Female Thread

Identification No.1 - Mounting Socket With Female Thread

Identification No.2 - Mounting Socket With Male Thread

Select Values to Buy:

Tech Spec:



GN782 Ball Joint, Steel

The clamping nut of these ball joints can be set to give a required thrust on the Belleville spring washers in order to increase the resistance to the ball movement.

At the same time the Belleville spring washers act as safety washers for the screws.

Once the maximum thrust to the Belleville spring washers is reached the ball arm is firmly immobilised in position over the clamping nut and screw.

Specification

Steel, zinc plated, blue passivated.

Brake piece - plastic, Technopolymer (Polyamide PA).

RoHS compliant

Select / Deselect Visible Columns
PartCoded1TypeIdentificationd2d3d4l1l2l3l4l5l6l7A/F1A/F2Recommended Tightening TorqueMaterialMass

GN782-M6-KS-1M6KS1M6178.510811202516.81615715ST0.046
GN782-M6-KS-2M6KS2M6178.510811202516.81615715ST0.05
GN782-M6-KI-1M6KI1M6178.510811202516.81615715ST0.046
GN782-M6-KI-2M6KI2M6178.510811202516.81615715ST0.05
GN782-M8-KS-1M8KS1M81911121012.52329.519.51817920ST0.068
GN782-M8-KS-2M8KS2M81911121012.52329.519.51817920ST0.075
GN782-M8-KI-1M8KI1M81911121012.52329.519.51817920ST0.067
GN782-M8-KI-2M8KI2M81911121012.52329.519.51817920ST0.075
GN782-M10-KS-1M10KS1M1021131512142633.523.520191135ST0.095
GN782-M10-KS-2M10KS2M1021131512142633.523.520191135ST0.112
GN782-M10-KI-1M10KI1M1021131512142633.523.520191135ST0.091
GN782-M10-KI-2M10KI2M1021131512142633.523.520191135ST0.108
GN782-M12-KS-1M12KS1M122816181520344427.728251445ST0.22
GN782-M12-KS-2M12KS2M122816181520344427.728251445ST0.252
GN782-M12-KI-1M12KI1M122816181520344427.728251445ST0.217
GN782-M12-KI-2M12KI2M122816181520344427.728251445ST0.108
