GN924.7 Spoked Safety Handwheel, Aluminium, Retractable Handle





B - Plain Bore

K - Keyway

R - With Revolving Handle

Select Values to Buy:

Tech Spec:

Product Description

GN924.7 Spoked Safety Handwheel, Aluminium, Retractable Handle

These spoked handwheels with retractable safety handle have a modern, attactive design. They are suitable for applications where the handle must not remain in the operating position.

In order to bring the handle into the operating position it must be pulled upward 90° against the torsion spring, to a stop and then pushed axially against the spring pressure into its hold position. By maintaining the forward thrust on the handle, the handwheel can easily be rotated. When the handle is released, the spring returns it back to the retracted position.

The removable plastic cover shrouds the fixing components such as screws, countersunk washers as well as the shaft end.

Specification

Aluminium die casting, hub machined, rim turned, plastic coated. Black, RAL2005, textured finish SW or Silver, RAL9006, textured finish SR

Rim concentric and square to bore <0.4

Retractable Safety Handle GN798.7

Countersunk Washer GN184

d2 - can be bore or keyway

RoHS compliant

Select / Deselect Visible Columns
PartCodeMateriald1d2d3d4bhl1l2l3rØ HandleBore CodeTypeColourMass

GN924.7-125-B12-R-SWAD12512233124.5418456245.522BRSW0.442
GN924.7-125-K12-R-SWAD12512233124.5418456245.522KRSW0.442
GN924.7-125-B12-R-SRAD12512233124.5418456245.522BRSR0.442
GN924.7-125-K12-R-SRAD12512233124.5418456245.522KRSR0.442
GN924.7-125-B14-R-SWAD12514233124.5418456245.522BRSW0.45
GN924.7-125-K14-R-SWAD12514233124.5418456245.522KRSW0.45
GN924.7-125-B14-R-SRAD12514233124.5418456245.522BRSR0.45
GN924.7-125-K14-R-SRAD12514233124.5418456245.522KRSR0.45
GN924.7-140-B14-R-SWAD140142336264194777.55224BRSW0.592
GN924.7-140-K14-R-SWAD140142336264194777.55224KRSW0.592
GN924.7-140-B14-R-SRAD140142336264194777.55224BRSR0.592
GN924.7-140-K14-R-SRAD140142336264194777.55224KRSR0.592
GN924.7-140-B16-R-SWAD140162336264194777.55224BRSW0.594
GN924.7-140-K16-R-SWAD140162336264194777.55224KRSW0.594
GN924.7-140-B16-R-SRAD140162336264194777.55224BRSR0.594
GN924.7-140-K16-R-SRAD140162336264194777.55224KRSR0.594
GN924.7-160-B14-R-SWAD160142336264204877.56124BRSW0.7
GN924.7-160-K14-R-SWAD160142336264204877.56124KRSW0.7
GN924.7-160-B14-R-SRAD160142336264204877.56124BRSR0.7
GN924.7-160-K14-R-SRAD160142336264204877.56124KRSR0.7
GN924.7-160-B16-R-SWAD160162336264204877.56124BRSW0.72
GN924.7-160-K16-R-SWAD160162336264204877.56124KRSW0.72
GN924.7-160-B16-R-SRAD160162336264204877.56124BRSR0.72
GN924.7-160-K16-R-SRAD160162336264204877.56124KRSR0.72
GN924.7-200-B18-R-SWAD200182342274245387.580.525BRSW1.046
GN924.7-200-K18-R-SWAD200182342274245387.580.525KRSW1.046
GN924.7-200-B18-R-SRAD200182342274245387.580.525BRSR1.046
GN924.7-200-K18-R-SRAD200182342274245387.580.525KRSR1.046
GN924.7-200-B20-R-SWAD200202342274245387.580.525BRSW1.035
GN924.7-200-K20-R-SWAD200202342274245387.580.525KRSW0.55
GN924.7-200-B20-R-SRAD200202342274245387.580.525BRSR1.035
GN924.7-200-K20-R-SRAD200202342274245387.580.525KRSR1.035
