Please select desired options to reveal part number, price and availability
Product Description
RS320 - Minimum Height, Maximum Force
Part of our most popular RS series of gas springs, these RS320 cylinders may be linked using Micro 32° hoses and feature the NEW OPAS (over pressure active safety) protection as standard. For further details, see Gas Spring Safety Information.
The RV Series is a development of the original series of HR cylinders, combining minimum height with enhanced forces. They are the ideal choice for every designer for any application, with a wide range of body diameters and initial forces available from stock.
Series RV replaces Series HR & HRF which have been phased out.
F1i = Isothermal end force at 100% Cu
F1p = Polytrophic end force at 100% Cu (See Techincal Data - Catalogue Specification for more information)
Specification
Connectable with Micro 32° hoses.
