GN212 Tension Lever, Steel, Plain or Threaded Bore

CloseNextPrevious



CloseNextPrevious

GN212: Tension Lever
Type: C - Angled lever with Plain Bore



CloseNextPrevious

GN212: Tension Lever
Type: E - Angled lever with Thread



CloseNextPrevious

GN212: Tension Lever
Type: B - Straight lever with Plain Bore



CloseNextPrevious

GN212: Tension Lever
Type: D - Straight Lever with Thread



CAD Viewer Technical Data

Series Selector

Options

Type C - Angled lever with plain bore, Tol. H7

Type E - Angled lever with threaded bore

Type B* - Straight lever with plain bore, Tol. H7

Type D* - Straight lever with threaded bore, Tol. H7

CAD Viewer Technical Data

Product Description

GN212 Tension Levers

These versatile tension levers, GN 212, are used as a clamping element as well as an operating lever. They are available with a plain or threaded bore.

Specification

Steel ST - blackened

Ball Knobs DIN319 - Plastic, Duroplast, black, shiny finish.

Also available in stainless steel.

* In addition to angled levers, a straight lever variant can be ordered. They are not usually available from stock, and require a minimum order quantity.
