Material Characteristics of Stainless Steel
Plastic Specification

CAD Data

GN292 3D CAD Model


GN292 Linear Actuator, Steel, Stainless Steel



GN292: Linear Actuator

CAD Viewer Technical Data

Series Selector


Type RL1 - Shaft End Protruding One End

CAD Viewer Technical Data

Product Description

GN292 Linear Actuator, Steel, Stainless Steel, Right or Left Hand Thread

In addition to the standard travel lengths specified in the above table for linear actuator GN 292 any length inside the maximum length is available.

Besides the extensive range of tube clamp connectors there are a number of additional components for mounting on the linear actuator to build slider units.

In order to measure the movement and positioning of the sliders, digital as well as analogue position indicators can be added and furthermore the guide tube can be provided with a longitudinal scale along the slot.


Guide tube, precision steel ST, chrome plated SCR, Stainless Steel NI AISI 304

Trapezoidal thread on shaft - Steel respectively. Stainless Steel NI AISI 303, Ball Bearing

Follower nut - Gunmetal.

End cap - plastic
